Neutrino

Raspberry Pi Configuration with LND

1. Download Raspberry Pi OS Lite

2. Format the SD Card

3. Enable SSH

# NOTE: If the microSD card has been mounted at /media/microSD, the command
# should be $ sudo touch /media/microSD/boot/ssh
$ touch /boot/ssh

4. Create file for Wi-Fi connection

$ nano /boot/wpa_supplicant.conf

------ START -------
country=ar
update_config=1
ctrl_interface=/var/run/wpa_supplicant

network={
 ssid="MyNetworkSSID"
 psk="password"
}
------ END -------

5. Connection

$ ssh [email protected]
password: raspberry

$ ifconfig

nmap -v 192.168.0.0/24

$ ssh [email protected]
password: raspberry

6. Configure the Pi

$ sudo raspi-config

• Select option (1) and change the password for the user pi.
• We select option (8) to update the configuration tool to the latest version
• We select option (4) to select our time zone
• We select option (7) and then Expand filesystem
• Finish

7. Now update the OS

$ sudo apt update && sudo apt upgrade -y
$ sudo apt install htop git curl bash-completion jq qrencode dphys-swapfile vim --install-recommends -y

8. Add the bitcoin user

$ sudo adduser bitcoin

9. Secure the rpi

$ sudo apt install ufw
$ sudo ufw default deny incoming
$ sudo ufw default allow outgoing
$ sudo ufw allow 22 comment 'allow SSH from LAN'
$ sudo ufw allow 9735 comment 'allow Lightning'
$ sudo ufw allow 10009 comment 'Lightning gRPC'
$ sudo ufw enable
$ sudo systemctl enable ufw
$ sudo ufw status
$ sudo apt install fail2ban

10. Install Go

$ wget https://golang.org/dl/go1.15.linux-armv6l.tar.gz
$ sudo tar -C /usr/local -xzf go1.15.linux-armv6l.tar.gz
$ echo "export PATH=$PATH:/usr/local/go/bin" >> ~/.bashrc
$ echo "export GOPATH=$HOME/go" >> ~/.bashrc
$ echo "export PATH=$PATH:$GOPATH/bin" >> ~/.bashrc
$ source ~/.bashrc
$ go version # should display the following message 'go version go1.13.5 linux/arm'

11. Compile and install LND

$ git clone https://github.com/lightningnetwork/lnd.git
$ cd lnd
$ make
$ make install tags="autopilotrpc chainrpc experimental invoicesrpc routerrpc signrpc walletrpc watchtowerrpc wtclientrpc"
$ sudo cp $GOPATH/bin/lnd /usr/local/bin/
$ sudo cp $GOPATH/bin/lncli /usr/local/bin/
$ lncli --version
lncli version 0.11.0-beta commit=v0.11.0-beta-61-g6055b00dbbcedf45cd60f12e57dc5c1a7b97746f

12. Create lnd conf file

$ sudo su - bitcoin
$ mkdir .lnd
$ nano .lnd/lnd.conf

[Application Options]
# enable spontaneous payments
accept-keysend=1

# Public name of the node
alias=YOUR_ALIAS
# Public color in hexadecimal
color=#000000
debuglevel=info
maxpendingchannels=5
listen=localhost
# gRPC socket
rpclisten=0.0.0.0:10009

[Bitcoin]
bitcoin.active=1
bitcoin.mainnet=1
bitcoin.node=neutrino

[neutrino]
neutrino.connect=bb2.breez.technology

13. LND service autostart

$ exit
$ sudo nano /etc/systemd/system/lnd.service

[Unit]
Description=LND Lightning Network Daemon
After=network.target

[Service]

# Service execution
###################

ExecStart=/usr/local/bin/lnd


# Process management
####################

Type=simple
Restart=always
RestartSec=30
TimeoutSec=240
LimitNOFILE=128000

# Directory creation and permissions
####################################

# Run as bitcoin:bitcoin
User=bitcoin
Group=bitcoin

# /run/lightningd
RuntimeDirectory=lightningd
RuntimeDirectoryMode=0710

# Hardening measures
####################

# Provide a private /tmp and /var/tmp.
PrivateTmp=true

# Mount /usr, /boot/ and /etc read-only for the process.
ProtectSystem=full

# Disallow the process and all of its children to gain
# new privileges through execve().
NoNewPrivileges=true

# Use a new /dev namespace only populated with API pseudo devices
# such as /dev/null, /dev/zero and /dev/random.
PrivateDevices=true

# Deny the creation of writable and executable memory mappings.
MemoryDenyWriteExecute=true

[Install]
WantedBy=multi-user.target

$ sudo systemctl enable lnd
$ sudo systemctl start lnd
$ systemctl status lnd

$ sudo journalctl -f -u lnd

14. Now we start LND

$ sudo su - bitcoin
$ lncli create

15. Add funds to the node

$ lncli newaddress p2wkh

$ lncli walletbalance
{
    "total_balance": "500000",
    "confirmed_balance": "0",
    "unconfirmed_balance": "500000"
}

$ lncli connect 031015a7839468a3c266d662d5bb21ea4cea24226936e2864a7ca4f2c3939836e0@212.129.58.219:9735

$ lncli openchannel 031015a7839468a3c266d662d5bb21ea4cea24226936e2864a7ca4f2c3939836e0 1000000 0

$ lncli walletbalance
$ lncli channelbalance

$ lncli pendingchannels
$ lncli listchannels

$ lncli payinvoice lnbc1p0kkhgwpp5sn9y6xe9hx7swrjj4057674vh73nwk6rxg8j8zedztkn3vdzgjafacqmud86h

$ lncli addinvoice --memo 'my first payment on LN' --amt 100

$ lncli getinfo

$ lncli

$ MACAROON_HEADER="Grpc-Metadata-macaroon: $(xxd -ps -u -c 1000 .lnd/data/chain/bitcoin/mainnet/admin.macaroon)"
$ curl -X GET --cacert .lnd/tls.cert --header "$MACAROON_HEADER" https://localhost:8080/v1/getinfo |jq
