As we have seen in previous chapters, digital signatures are often used to unlock the script of an input. In the signing process, it is necessary to include the signed data in the calculation, designated in our examples by the message

. This data, once signed, cannot be modified without rendering the signature invalid. Indeed, whether for ECDSA or Schnorr, the signature verifier must include in their calculation the same message

. If it differs from the message

initially used by the signer, the result will be incorrect and the signature will be deemed invalid. It is then said that a signature covers certain data and protects it, in a way, against unauthorized modifications.

What is a sighash flag?

In the specific case of Bitcoin, we've seen that the message

corresponds to the transaction. However, in reality, it's a bit more complex. Indeed, thanks to sighash flags, it's possible to select specific data within the transaction that will be covered or not by the signature. The "sighash flag" is thus a parameter added to each input, allowing the determination of the components of a transaction that are covered by the associated signature. These components are the inputs and the outputs. The choice of the sighash flag thus determines which inputs and which outputs of the transaction are fixed by the signature and which can still be modified without invalidating it. This mechanism allows signatures to commit transaction data according to the signer's intentions.

Obviously, once the transaction is confirmed on the blockchain, it becomes immutable, regardless of the sighash flags used. The possibility of modification via the sighash flags is limited to the period between the signing and the confirmation.

Generally, wallet software does not offer you the option to manually modify the sighash flag of your inputs when you construct a transaction. By default, SIGHASH_ALL is set. Personally, I only know of Sparrow Wallet that allows this modification from the user interface.

What are the existing sighash flags in Bitcoin?

In Bitcoin, there are first and foremost 3 basic sighash flags:

SIGHASH_ALL (0x01): The signature applies to all the inputs and all the outputs of the transaction. The transaction is thus entirely covered by the signature and can no longer be modified. SIGHASH_ALL is the most commonly used sighash in everyday transactions when one simply wants to make a transaction without it being able to be modified.

In all the diagrams of this chapter, the orange color represents the elements covered by the signature, while the black color indicates those that are not.

SIGHASH_NONE (0x02): The signature covers all the inputs but none of the outputs, thus allowing the modification of the outputs after the signature. In concrete terms, this is akin to a blank check. The signatory unlocks the UTXOs in inputs but leaves the field of outputs entirely modifiable. Anyone knowing this transaction can thus add the output of their choice, for example by specifying a receiving address to collect the funds consumed by the inputs, and then broadcast the transaction to recover the bitcoins. The signature of the owner of the inputs will not be invalidated, as it covers only the inputs.

SIGHASH_SINGLE (0x03): The signature covers all inputs as well as a single output, corresponding to the index of the signed input. For example, if the signature unlocks the scriptPubKey of input #0, then it also covers output #0. The signature also protects all other inputs, which can no longer be modified. However, anyone can add an additional output without invalidating the signature, provided that output #0, which is the only one covered by it, is not modified.

In addition to these three sighash flags, there is also the modifier SIGHASH_ANYONECANPAY (0x80). This modifier can be combined with a basic sighash flag to create three new sighash flags:

SIGHASH_ALL | SIGHASH_ANYONECANPAY (0x81): The signature covers a single input while including all outputs of the transaction. This combined sighash flag allows, for example, the creation of a crowdfunding transaction. The organizer prepares the output with their address and the target amount, and each investor can then add inputs to fund this output. Once sufficient funds are gathered in inputs to satisfy the output, the transaction can be broadcast.

SIGHASH_NONE | SIGHASH_ANYONECANPAY (0x82): The signature covers a single input, without committing to any output;

SIGHASH_SINGLE | SIGHASH_ANYONECANPAY (0x83): The signature covers a single input as well as the output having the same index as this input. For example, if the signature unlocks the scriptPubKey of input #3, it will also cover output #3. The rest of the transaction remains modifiable, both in terms of other inputs and other outputs.

Projects to Add New Sighash Flags

Currently (2024), only the sighash flags presented in the previous section are usable in Bitcoin. However, some projects are considering the addition of new sighash flags. For example, BIP118, proposed by Christian Decker and Anthony Towns, introduces two new sighash flags: SIGHASH_ANYPREVOUT and SIGHASH_ANYPREVOUTANYSCRIPT (AnyPrevOut = "Any Previous Output").

These two sighash flags would offer an additional possibility in Bitcoin: creating signatures that do not cover any specific input of the transaction.

This idea was initially formulated by Joseph Poon and Thaddeus Dryja in the Lightning White Paper. Before its renaming, this sighash flag was named SIGHASH_NOINPUT. If this sighash flag is integrated into Bitcoin, it will enable the use of covenants, but it is also a mandatory prerequisite for implementing Eltoo, a general protocol for second layers that defines how to jointly manage the ownership of a UTXO. Eltoo was specifically designed to solve the problems associated with the mechanisms for negotiating the state of Lightning channels, that is, between opening and closing.

To deepen your knowledge of the Lightning Network, after the CYP201 course, I highly recommend the LNP201 course by Fanis Michalakis, which covers the topic in detail:
